Page 6
1. Fasten the outside antenna to the mounting bracket with the supplied
screws and washers (see page 5).
2. Connect the separate 25’ cable to the antenna (LARGE CONNECTOR).
3. Apply roof-compatible sealant around the areas where the bracket fasteners
will penetrate the roof.
TIP
If your vehicle has a pre-wire enclosure on the roof, you can use
the included pre-wire kit for installation (see instructions in kit).
INSTALLATION
KC1296
AVOID SHARP BENDS WHEN ROUTING COAX!
