45
FPCSP46-2
In more detail . . .
4.
Remove any dirt accumulated inside the guide bar slot using the putty knife (not
provided) (Fig. 45).
45
5. Check the guide bar “rail” for wear: Hold a ruler (straight edge) against the side of
the guide bar and “cutter side plates”. If there is a gap between the ruler and guide
bar the guide bar “rail” is normal. If there is no gap (ruler ush against the side of
the guide bar) the guide bar “rail is worn and needs to be replaced with a new one
of the same type (Fig. 46).
46
6. Turn the guide bar 180° to allow even wear, thereby extending the life span of the
guide bar.
7. Check the saw chain for possible wear and damages. Replace it with a new one if
required. Experienced user can sharpen a dull saw chain (see section “Saw chain
sharpening” below).
8. Ret the saw chain and the guide bar as described under section “Assembly”.
Saw chain sharpening
NOTE: Never saw with a blunt chain. The saw chain is blunt if you have to
push the product into the tree and the chips are very small.
1.
Have the saw chain (3) sharpened professionally at an authorised service centre
or sharpen the chain yourself by using a proper sharpening kit. Also observe the
sharpening instructions supplied with the sharpening kit.
WARNING! Only sharpen the saw chain yourself if you are trained and have
experience! Use proper tools to sharpen the saw chain!
Care and maintenance
