2. Specifications
M o d e l D K 4 5 D K 5 0
Maximum PTO power 3 8 H P 4 1 . 5 H P
Engine GROSS power 4 5 H P 4 9 H P
M o d e l 4 A 2 2 0 4 A 2 0 0 T
T y p e
Indirect injection, vertical, water-cooled, 4-cycle diesel engine
Indirect injection, vertical, water-cooled, 4-cycle diesel engine(Turbo)
Number of cylinder 4 4
Bore and stroke 87*92.4 mm (3.425*3.638 in.) 83*92.4 mm (3.268*3.638 in.)
Total displacement 2197 cc 2000 cc
Rated revolution 43.3 rps (2600 rpm) 43.3 rps(2600 rpm)
E n g i n e Injection timing 1 8
o
before T.D.C. 2 0
o
before T.D.C.
Injection order 1 - 3 - 4 - 2 1 - 3 - 4 - 2
Compression ratio 2 2 2 2
Lubricating system
Forced lubrication by trochoid pump Forced lubrication by trochoid pump
Cooling system
Pressurized radiator, Forced circulation with water pumpPressurized radiator, Forced circulation with water pump
A l t e r n a t o r 12V, 50AMPS 12V, 50AMPS
Weight (Dry) 207 kg 211 kg
Fuel tank 40L(42.3 u.s.qts.) 40L(42.3 u.s.qts.)
Engine crankcase 7.0L(7.4 u.s.qts.) 7.0L(7.4 u.s.qts.)
C a p a c i t i e s Engine coolant 8.9L(9.4 u.s.qts.) 8.9L(9.4 u.s.qts.)
Transmission case 34L(35.9 u.s.qts.) 34L(35.9 u.s.qts.)
Front axle case 8.2L(8.6 u.s.qts.) 8.2v(8.6 u.s.qts.)
Overall length (without 3p) 3073 mm (120.9 in.) 3073 mm (120.9 in.)
Overall length (with 3p) 3323 mm (130.8 in.) 3323 mm (130.8 in.)
Overall width (minimum tread) 1550 mm (61.0 in.) 1550 mm (61.0 in.)
Overall height (Top of ROPS) - -
Overall height (Top of steering wheel) 1610 mm (63.3 in.) 1610 mm (63.3 in.)
Wheel base 1820 mm (71.6 in.) 1820 mm (71.6 in.)
Min. ground clearance 370 mm (14.5 in.) 370 mm (14.5 in.)
Front mm (in) 1265 mm (49.8 in.) 1265 mm (49.8 in.)
Rear mm (in) 1180 ~ 1490 mm (46.4 ~58.6 in.) 1180 ~ 1490 mm (46.4 ~58.6 in.)
Tire size Front 9.5 - 16.6 PR 9.5 - 16.6 PR
(Std. tires) Rear 14.9 - 24.8 PR 14.9 - 24.8 PR
C l u t c h Dry type single plate-single stage Dry type single plate-single stage
S t e e r i n g Hydraulic power steering Hydraulic power steering
Synchronized shuttle and transmission Synchronized shuttle and transmission
T r a n s m i s s i o n
(8 forward and 8 reverse speeds) (8 forward and 8 reverse speeds)
T r a v e l i n g Wet disc type Wet disc type
P a r k i n g Connected with the traveling brake Connected with the traveling brake
D i f f e r e n t i a l Bevel gear Bevel gear
Hydraulic lift control system Position, Draft and Mixed control Position, Draft and Mixed control
Pump capacity (Max, flow rate) Main pump 31.2 l/min Main pump 31.2 l/min
Power steering pump 18.7 l/min Power steering pump 18.7 l/min
Three point hitch SAE Category l SAE Category l
Maximum lifting capacity
1050 kg 1050 kg
(24 in, behind lower link end)
2
No. of Remote control valve ports 2
PTO shaft SAE 1-3/8, 6 splines SAE 1-3/8, 6 splines
Revolution (independent PTO) 5 6 0 5 6 0
Min. turning radius (with brake) 2865 mm (112.7 in.) 2865 mm (112.7 in.)
Traction system
Fixed drawer (or swing drawer - OPTION) Fixed drawer (or swing drawer - OPTION)
Weight (with ROPS) 1 7 2 0 k g 1 7 3 0 k g
Traveling speed (at rated engine speed with Std. tires) 1st ~8th : 1.78 ~25.5 km/h 1st ~8th : 1.78 ~25.5 km/h
NOTE : * Manufacturer’s estimate
Dimensions
(with Std. tires)
T r a v e l i n g
system
H y d r a u l i c
system
PTO
Tread
Brake
