As a guide to the operation of your tractor, various universal symbols have been utilized on the
instruments and controls. The symbols are shown below with an indication of their meaning.
Safety Alert Symbol
Diesel Fuel
F u e l - L e v e l
Engine-Rotational Speed
Hourmeter/Elapsed Operating Hours
Engine Coolant-Te m p e r a t u r e
Diesel Preheat/Glow Plugs(Low
Temperature Start Aid)
Parking Brake
Engine Intake/Combustion Air-Filter
Battery Charging Condition
Engine Oil-Pressure
Turn Signal
E n g i n e - S t o p
E n g i n e - R u n
Starter Control
Engine-Emergency stop
Power Ta k e - O f f Clutch Control-Off Position
Power Ta k e - O f f Clutch Control-On Position
D i fferential Lock
Position Control-Raised Position
Position Control-Lowered Position
Draft Control-Shallow Position
Draft Control-Deep Position
3-Point Lowering Speed Control
Remote Cylinder-Retract
Remote Cylinder-Extend
Steering Wheel-Tilt Control
Hazard Warning Lights
Master Lighting Switch
Position Lamps
Headlight-Low Beam
Headlight-High Beam
Audible Warning Device
Four-Wheel Drive-On
Four-Wheel Drive-Off
F a s t
S l o w
C r e e p
Read Operator’s Manual
Tractor-Forward Movement-Overhead
View of Machine
Tractor-Rearward Movement-Overhead
View of Machine
Engine Speed Control
Universal Symbols
