Kioto Solar FWS 20 E - Cascade Circuit

16
E & OE, subject to change without notice.
Cascade Circuit
1 Fresh Water Station – Station 1
2 Fresh Water Station – Station 2
3 Fresh Water Station – Station 3
(max. 3 stations)
4 Circulation unit (optional)
5 Overowvalve
A Buffer water return
B Bufferwaterow(1300l/hperstation)
C Tap water (hot)
D Circulation return (optional)
E Tap water supply
A
B
C
D
4
E
1
2
3
5
35 kPa
5
25 kPa
Advices
Die domestic hot water (DHW) temperature is dependent from the buffer temperature, the tapping quantity and the cold
watertemperate.Themixingvalvecompensatesthetemperatureuctuations.Theadjustmentofthethermostatheadand
the DHW temperature shown in the table below are indicative. Actual DHW temperature may vary.
Thermostatic head 0 1 2 3 4 5
DHW-temperature 30 34 38 42 46 50 54 58 62 66 70
Thermostat settings
