Kipor IG3000E Operator's Manual

1. SAFETY INSTRUCTIONS
The generators are designed to give safe and dependable
service if operated according to instructions.
Read and understand the Owner's Manual before
operating the generator. Failure to do so could result in
personal injury or equipment damage.
Exhaust gas contains poisonous carbon monoxide. Never
run the generator in an enclosed area.
Be sure to provide adequate ventilation.
The muffler becomes very hot during operation and
remains hot for a while after stopping the engine.
Be careful not to touch the muffler while it is hot.
Let the engine cool before storing the generator indoors.
WARNING
WARNING
WARNING

Kipor IG3000E Specifications

General

Type	Inverter
Engine Model	KG205
Engine Type	4 stroke, overhead valve, single cylinder
Displacement	12.0 cu in (196 cc)
Compression Ratio	8.5:1
Cooling System	Forced Air
Ignition System	Transistorized
Spark Plug	F6RTC
Rated Voltage	120
Frequency	60 HZ
DC Output	12V@8.3A
Maximum Output	3000W, 25A
Rated Output	2800W, 23.3A
Engine Speed	3600 rpm with smart throttle off
Rated Load Run Time	5.6 hrs
Oil Capacity	.57 qt (0.6L)
Fuel Tank Capacity	2.5 gal (9.5 L)
Noise Level- no load-full load @ 23' (7m)	70-74 dB

Weight and Dimensions

Length	15.75 in (400 mm)
Width	19.3 in (490 mm)
Height	16.9 (430 mm)
Weight	77 lbs (35 kg)
