Kipor Sinemaster IG3000 Operation Manual

28
10. SPECIFICATIONS
Model
IG3000
Type
Inverter
Rated Voltage
120
Frequency
60 HZ
Maximum Output
3000W, 25A
Rated Output
2800W, 23.3A
DC Output
12V@5.0A
Engine Model
KG205
Engine Type
4 Stroke, overhead valve, single cylinder
Displacement
12.0 cu in (196 cc)
Compression Ratio
8.5:1
Engine Speed
3600 rpm with smart throttle off
Cooling System
Forced Air
Ignition System
Transistorized
Oil Capacity
0.63 qt (0.6L)
Fuel Tank Capacity
3.1 gal (11.6 L)
Rated Load Run Time
6.25 hours
Noise level-no load-full load @ 23’ (7m)
62-67 dB
Spark Plug
WR7DC
Length
27.0 in (686 mm)
Width
16.7 in (425 mm)
Height
19.9 in (505 mm)
Weight
132 lbs (60 kg)
Tune Up Specifications
Spark Plug Gap
0.024-0.028 in (0.6-0.7 mm)
Valve Clearance- cold (Intake)
0.0039 ±.0008 in (0.10 ± 0.02 mm)
Valve Clearance- cold (Exhaust)
0.0059 ± .0008 in (0.10 ± 0.02 mm)

Kipor Sinemaster IG3000 Specifications

General

Rated Power	2.8 kW
Maximum Power	3.0 kW
Max. AC Output	3.0 kVA
Rated Voltage	230 V
Rated Frequency	50 Hz
Power Factor	1.0
Engine Type	4-stroke, OHV, single cylinder
Displacement	196 cc
Fuel Type	Unleaded Gasoline
Fuel Tank Capacity	13 L
Starting System	Recoil start
Noise Level	65 dB at 7 m
