Kipor Sinemaster IG3000 Operation Manual

8
4. STARTING THE ENGINE
■When starting the generator after adding fuel for the first time or after
long term storage, or after running out of fuel, turn the fuel valve lever
to the "ON" position, then wait for 10 to 20 seconds before starting
the engine.
4.1 Starting Procedure
4.1(a) Turn the fuel valve lever to the ON position.
Fig.6
4.1(b) Pull the choke knob out to the CLOSED position
Do not use the choke if the engine is already warm or the ambient air temperature is high.
Fig.7
Fuel valve lever
Choke knob

Kipor Sinemaster IG3000 Specifications

General

Rated Power	2.8 kW
Maximum Power	3.0 kW
Max. AC Output	3.0 kVA
Rated Voltage	230 V
Rated Frequency	50 Hz
Power Factor	1.0
Engine Type	4-stroke, OHV, single cylinder
Displacement	196 cc
Fuel Type	Unleaded Gasoline
Fuel Tank Capacity	13 L
Starting System	Recoil start
Noise Level	65 dB at 7 m
