14. EMISSION CONTROL SYSTEM
If so designated, your generator has an engine that has been approved by the California Air
Resources Board. Other than the tune up procedures specified in the maintenance section, no
additional maintenance is required.
The emission control system has the following components:
1. Fuel System: The fuel tank, cap, indicator and hoses are specially designed and constructed
to not allow fuel vapors to permeate and be released to the atmosphere.
2. A carbon activated canister collects gasoline vapors from the fuel tank and returns them to the
combustion chamber for burning.
3. A catalyst is built into the muffler to further treat the engine exhaust.
4. A secondary air injection valve adds combustion air to ignite unburned fuel in the exhaust.
Contact your authorized Kipor service center to obtain the correct replacement parts and service on
this system.
Inlet System
空滤器底壳
六角法兰面螺母M6
滤芯组件
空滤器盖
接碳罐负压管
主量孔
(出厂前已调节)
化油器部件
Air filter housing
Flange nut M6
Filter element
Air filter cover
Carburetor
Main metering jet
Canister
connection

Kipor Sinemaster IG3000 Specifications

General

Rated Power	2.8 kW
Maximum Power	3.0 kW
Max. AC Output	3.0 kVA
Rated Voltage	230 V
Rated Frequency	50 Hz
Power Factor	1.0
Engine Type	4-stroke, OHV, single cylinder
Displacement	196 cc
Fuel Type	Unleaded Gasoline
Fuel Tank Capacity	13 L
Starting System	Recoil start
Noise Level	65 dB at 7 m
