Kirisun PT3600 Service Manual

PT3600 Service Manual
11
No. Part No. Description PCS Remark
1 7MHR-7123-01A-W9 Light guide 1 Silica gel, transparent, ROHS
2 7PLJ-7123-E01A LOGO 1
3 7MHP-7123-05A-W0 Cover for external speaker/MIC jacks 1 TPU, black, ROHS
4 7MHP-7123-01A-W0 Front casing 1 PC+ABS, black, ROHS
5 7GCB-360001-W0 Protective net for speaker 1
Black waterproof cloth, diameter 36mm* thick
0.1mm
6 7GCB-070005 Dustproof net for MIC 1
Black non-woven cloth, diameter 7mm* thick
0.5mm, waterproof
7 7SMF-020040M-SZYB-N1 M2.0*4.0 pan plus machine screws 8 For fixing the PCB
8 7MHR-1727-09A-W3 MIC waterproof 1 Silica gel, hardness 40, orange, no surface treatment
9 6PM7-7115-HMA PT3600 mainboard 1
10 7MHR-7042-05A-W0 PT568 waterproof gasket for bracket 1 Silica gel, black, hardness 60, ROHS
11 7MHP-7042-11A-W PT568 battery connector assembly 1
12 7MHP-7123-07A-W0 MIC/SPK jack cover plug 1 PC+ABS, black, ROHS
13 7SMF-020080M-MHHT-N1 M2*8 Torx thick head machine screws 2 For fixing Al alloy chassis
14 7MDP-7126-02A-W0 Battery bottom casing 1 PC+ABS, black, ROHS (with hardware piece)
15 6BPM-063760-074130-A KB-31A Li-poly battery pack 1 M063760Q01,TCL,7.4V,1300mAh, ROHS
16 7MDP-7126-01A-W0 Battery top casing 1 PC+ABS, black, ROHS (with hardware piece)
17
7MJP-1740-02A-W0
(7ML-1826-01A-L0,
7MJS-1826-01A-W)
KBJ-05 Belt clip bracket (metal bracket) 1 PC+ABS, black, ROHS (Al alloy, stainless steel)
18 7MJS-7128-01A-N KBJ-10 Belt clip bolt 1 Carbon steel, Ni-plated, ROHS
19 7MJP-7128-01A-W0 Belt clip 1 PC+ABS, black, ROHS
20 7MJS-3851-02A-W KBJ-01 Spring 1 Stainless steel, ROHS
21 7SMF-025050M-MHYB-Z2
M2.5*5 Pan torx black Zn-
p
lated
machine screws
2 For fixing the top cover
22 7MHP-7123-08A-W0 Battery latch 1 PC+ABS, black, ROHS
23 7MHS-1727-02A-N Battery latch spring 1 Carbon Spring Wire 0.35,∮ Ni-plated, ROHS
24 7MHP-7123-06A-W0 Top cover 1 PC+ABS, black, ROHS
25 7MHR-7123-02A-W0 Main waterproof 1 Black silica gel, hardness 45, ROHS
26 7MHL-7123-01A-WA Al alloy chassis 1 ADC12, abrasive, polished, ROHS
27 3CR7-SMA-50JFB-4 PT558 antenna connector 1 Ni-plated brass, ROHS
28 7SMF-020040M-SZYB-N1 M2.0*4.0 Pan plus machine screws 2 For fixing the antenna connector
29 7NRC-060100035-B1 Switch nut 2
Brass, inner diameter M6mm, outer diameter
10mm, thick 3.5mm, black passivation
30 7NRC-090136039-B1 Antenna nut 1
Brass, inner diameter M9mm, outer diameter
13.6mm, thick 3.9mm,
31 3SE3-RE08140AX-V01 Encoder switch 1
32 2RW3-R08710NS-A103 Volume potentiometer 1
33 7MHP-1010-15A-W 3208 PVC MIC gasket 1 Transparent PVC, 0.5mm thick
34 4SS7-4005-016-100B 7200 speaker 1
40*H4.8, impedance 16, power 1W, gold-plated
35 7MHP-7123-04A-W0 PTT button cover 1 PC+ABS, black, ROHS
36 7MHR-7123-03A-W0 PTT button 1 Black silica gel, hardness 60, ROHS
37 xxxxxxxxx PT3600 antenna 1
38 7MHP-7123-03A-W3 Channel selector knob 1 ABS, black, painted, ROHS
39 7MHP-7123-02A-W0 Volume knob 1 ABS, black, painted, ROHS
40 7MHR-7123-04A-W3 Emergency button 1 Orange silica gel, hardness 60, ROHS
