TM840 Service Manual
303 2RS1-16-4R7J Chip Resistance 1 FB6
304 1DS1-DA2S10100L R Chip switching diode 1 D18
305 1DS1-DAN222 R Chip switching diode 1 D17
306 2RS1-16-101J R Chip Resistance 6 R19，R20，R21，R22，R23，R24
307 2RS1-16-151J R Chip Resistance 1 R27
Table2 136-174MHz Parts List(Electrics Section)
No. Part No. Part Name Quantity Location
1 0SS1-4105-HMC SxM8010H/G mainboard SMT material 1
2 6PM7-4105-HMB Sepura mainboard PCB 1
3 5XC1-32R8-FC-135
oscillator
1 X500
6 5XC1-18R4-CEC5032SCH SMD crystal oscillator STM,DP780 1 X801
7 5FQ1-LFCN-180 Low-pass filter 2 U43,U47
8 5FE1-BLM11A601S R SMD EMI suppression filter 17 FB23,FB24,FB26,FB27,FB30,FB203,R6038,R6045,R6046,R6047,R6048,R6049,R6050,R6051,L11 ,L1003,L1004
9 5FE1-BLM18PG181SN1 SMD EMI suppression filter 14 FB25,FB3,FB4,FB5,FB6,FB7,FB8,FB41,FB43,FB44,FB13,FB14,FB31,FB32
10 5FE1-BLM41P600SPT R SMD EMI suppression filter 3 FB28,L6,L13
11 5FE1-BLM21PG221SN1 SMD EMI suppression filter 6 FB73,FB12，FB21，FB22，FB59，FB60
12 5FE1-BLM15AG221SN1D EMI suppression filter 39
R818,FB64，FB65，FB66，FB67，FB68，FB70，FB71，FB69,FB9，FB61，FB62，FB38，FB39，FB40，FB42，FB45，FB46，FB47，FB48，
FB49，FB50，FB51，FB52，FB53，FB10，FB11，FB55，FB56，FB63，FB36，FB54，FB37，FB72，FB807，FB1，FB2，FB57，FB58
13 3FW1-42932-302320 R SMD fuse 1 FB19
14 1DS1-DA2S10100L R SMD switching diode 9 D4,D6,D7,D37,D1001,D12，D44，D45,D11
15 1DS1-HVC131 R SMD switching diode (out of production) 6 D10,D18，D41,D40，D42，D43
16 1DS1-L8104
by1DS1-L709CE）
3 D27,D29，D39
17 1DS1-RB706F-40 R SMD switching diode 3 D31,D103,D38
18 1DV1-HVC350B R SMD varactor (out of production) 24 D67、D68、D69、D70、D71、D72、D73、D74、D75、D76、D77、D78、D79、D80、D81,D19,D28,D24,D33，D13,D14,D15,D3015,D3017
19 1DV1-1SV305 R SMD varactor 18 D117,D116,D4000,D125,D126,D121,D122,D113,D105,D107,D108,D109,D26,D111,D101,D102,D25,D106
20 1DV1-HVC376B R SMD varactor (out of production) 1 D4001
21 1DG1-DSM3MA1 R SMD conventional diode 1 D8
22 1DR1-SS36 SMD rectifier diode 1 D1
47
