TM840 Service Manual
23 1DZ1-HZU5CLL R SMD zener diode (out of production) 1 D35
24 1DZ1-PESD24V0S1UB SMD zener diode 1 D17
25 1DZ1-PESD3V3S1UB SMD zener diode 6 D61，D57，D62，D58，D59，D60,
26 1DZ1-PESD5V0S1UB SMD zener diode DP770，DP780，STP,KH620 14 D55，D51，D50，D49，D20，D21，D22，D46，D47，D48，D52，D53，D54，D56
27 1DR1-SMCJ20A SMD diode 1 D2
28 4PE1-16-F2-G R SMD LED 1 LED2
29 1DZ1-LM3Z18VT1G SMD zener diode 1 D16
30 1DZ1-BZB784-C3V3 zener diode 1 D3
31 1TF1-2N7002 SMD FET 1 Q11
32 1DG1-CM1293A SMD conventional diode 3 U13,U14,U15
33 6BLS-4814-03327U
SMD button battery (DP770 ， DM890 ，
PT7800,219,620D)
1 BT1
34 3CF1-40FMN-SMT-A-TF R SMD FFC/FPC connector 1 J5
35 3CC1-USB-UH51543-CS7 USB port AB-type jack 1 J24
36 3CR1-MM9329-2700 RF coaxial connector 1 C91
37 1TT1-DTA144EE R SMD triode 1 Q56
38 1TT1-2SC4617-R R SMD triode 6 Q1005,Q13,Q54，Q25,Q52，Q57
39 1TT1-DTC144EE R SMD triode 26 Q3,Q4,Q6,Q7,Q8,Q9,Q20,Q21,Q23,Q32,Q33,Q34,Q35,Q36,Q37,Q38,Q39,Q40,Q41,Q42,Q43,Q44,Q45,Q59,Q4001，Q60
40 1TT1-DTC114YE SMD triode 5 Q31，Q46，Q53,Q104,Q5
41 1TF1-PHD27NQ10T SMD FET 1 Q1
42 1TT1-FMMT717TA R SMD triode 3 Q47,Q50,Q103
43 1TF1-ST2301 R SMD FET 4 Q2,Q10,Q61，Q58
44 1TT1-2SC3356-R24 R SMD triode 9 Q26,Q27,Q4000,Q28,Q29,Q24,Q18,Q19,Q55
45 1IS1-XC6209F502PR SMD regulator IC 6 Q12,Q16,Q17,Q22,Q30,Q51
46 1IS1-XC6209B552MR SMD regulator IC 1 Q14
47 1IS1-XC6209F332PR SMD regulator IC 2 Q4002,Q15
48 1IS1-XC6228D122VR SMD specialized IC SPURAL FP520 FM540 1 U12
49 1IS1-LM2941S SMD specialized IC 1 U16
50 1IS1-PGA103 Broadband low noise amplifier 2 U31,U36
51 1IS1-GVA63 High-gain amplifier 2 U42,U46
52 1IS1-GVA84 High-gain amplifier 1 U51
53 1IS1-TPS65023
Power management chip DP770， DP780，
KH620D,STR,STP
1 U3
54 1IS1-RT9193-33PB SMD regulator IC 1 U10
55 3CP1-TPS76301 LDO power regulator 1 U112
56 1IS1-TPS2051BDGN LDO power regulator IC 1 U7
57 1IS1-LT4356-1 Overvoltage protector IC 1 U2
58 1IS1-AD9864 IF digital system 1 U4000
59 1IS1-ADS1015 AD convertor IC 2 U11,U22
48
