TM840 Service Manual
60 1IS1-MAX98400B D-type high power amplifier 1 U18
61 1IS1-MC74VHC1GT66 High-speed CMOS analog switching IC 2 U30,U110
62 1IM1-MT47H64M16 SMD memorizer IC 1 U5
63 1IP1-OMAPL138BZWT3 Dual-core CPU 1 U4
64 1IS1-PCF8563TS SMD specialized IC 1 U20
65 1IS1-SKY72310 PLL chip 1 U103
66 1IS1-SYM25DHW SMD frequency mixer 1 IC3003
67 1IS1-TA75W01FU R SMD specialized IC 1 U25
68 1IS1-TLV5614 DA convertor chip 1 U105
69 1IS1-TLV320AIC3104 SMD audio decoding IC 1 U17
70 1IS1-TPS54331DDA SMD switching power IC 1 U1
71 1IS1-TS3A4751PWR SMD SPST analog switching IC 1 U34
72 1TC1-UMC4 R SMD multiunit tube 5 U26,U27,U28,U108,U109
73 1IS1-XC0450E20S Directional coupler 1 U48
74 1IS1-TC75S51F SMD single operational amplifier IC 1 U21
75 1IS1-AD8315 50dB GSM power amplifier controller 1 IC2
76 1IS1-AD8566 Dual operational amplifier 2 IC1，IC3
77 2RS1-10-201J Chip resistor 5 R120，R129，R130，R122，R128
78 2RS1-10-102J R Chip resistor 5 R152，R145，R121，R144，R151
79 2RS1-10-000O R Chip resistor 3 R127，R123，R38
80 2RS1-10-472J R Chip resistor 8 R161，R162，R165，R178，R181，R183，R184，R163
81 2RS1-10-103J R Chip resistor 22
R164，R168，R171，R172，R173，R175，R179，R180，R169，R167，R174，R188，R133，R134，R189，R386，R125，R155，R146，
R139，R148，R142
82 2RS1-10-512J R Chip resistor 2 R182，R131
83 2RS1-10-203J R Chip resistor 2 R170，R387，
84 2RS1-10-185J R Chip resistor 1 R379
85 2RS1-10-473J R Chip resistor 1 R385
86 2RS1-10-101J R Chip resistor 5 R278，R309，R321，R383，R390
87 2RE1-16-1002 R SMD precision resistor 2 R1，R238
88 2RS1-16-334J R Chip resistor 1 R2
89 2RS1-16-104J R Chip resistor 17 R433、R434、R435、R436、R437,R22,R5,R9,R16,R113,R114,R115,R4006，R289,R10,R20,R425
90 2RE1-16-2001 SMD precision resistor 8 R106,R12,R251,R192,R232，R291,R18,R389
91 2RS1-16-474J R Chip resistor 2 R13，R343
92 2RS1-16-100J R Chip resistor 2 R4,R21
93 2RS1-16-683J R Chip resistor 3 R6,R358,R325
94 2RS1-16-513J R Chip resistor 1 R7
95 2RS1-16-154J R Chip resistor 1 R11
96 2RS1-16-393J R Chip resistor 5 R292,R356,R371，R333,R406
