KitchenAid 5FVSP - Food Grinder Attachment; Assembling the Food Grinder

3
English
Food Grinder Attachment
To Assemble Food Grinder Attachment
1. Insert the grind worm (A) into the grinder body (B).
2. Place the knife (C) over the square shank at the exposed end of the grind worm.
3. Place grinding plate (D) over the knife, matching the tabs of the plate with the
notches of the grinder body.
4. Place ring (E) on grinder body, turning by hand until secured but not tightened.
NOTE: The combination food pusher/wrench (F) is used for removal of ring (E) only.
Do not use it to tighten ring (E).
NOTE: Fruit/Vegetable Strainer (Model 5FVSP) is available to convert Food Grinder to
a Fruit/Vegetable Strainer. Sausage Stuffer (Model 5SSA) is available to convert Food
Grinder to Sausage Stuffer.
Fine
B
Coarse
A
E
F
C
D
