5
English
Fruit/Vegetable Strainer
To Assemble Fruit/Vegetable Strainer
1. Slide the smaller end of spring and shaft assembly (A) into opening in larger worm (B)
until secured firmly in place.
2. Insert the larger worm into the grinder body (C).
3. Attach strainer cone (D) over the exposed end of the worm matching the tabs of the
cone with the notches in the grinder body (C).
4. Place ring (E) onto the grinder body, turning by hand until finger tight, but
not overtightened.
NOTE: The combination food pusher/wrench (F) is used for removal of ring (E) only. Do
not use it to tighten ring (E).
5. Slide the strainer tray (G) over the cone and latch on the top of ring.
6. Place splash shield (H) on strainer tray (G).
E
H
G
C
A
D
B
F
