ASSEMBLING THE JUICER
PARTS AND ACCESSORIES
Assembling the Juicer parts
Alignment
marks
2
Slide the gasket into place behind
the pulp chute.
1
Slide the pulp chute onto the bottom of
the bowl.
Before First Use
Before using your Juicer for the first time, wipe Juicer parts with a warm damp cloth, then
wipe clean with a damp cloth. Do not wash the gear housing assembly. Dry with a soft
cloth. See “Care and Cleaning” section.
3
Place the bowl into the drive assembly.
4
Put the screen wiper basket into
the bowl.
5
Place the screen of your choice into the
screen wiper basket with the alignment
marks directly above the pulp chute.
Pulp chute
6
Place the auger/blade assembly inside
the screen.
