KitchenAid 720-0733D - REPLACEMENT PARTS CATALOG; Detailed Parts List and Warranty Info

No. Part (Description)
Warranty
coverage
(Year)
QTY
N
o.
Part (Description)
Warranty
coverage
(Year)
QTY
1 Main Lid 3 1 33 Grease cup 1 1
2 Main Lid screw 3 2 34 Door hinge 1 4
3 Temperature gauge housing 1 1 35 Door handle assembly 1 2
4 Temperature gauge 1 1 36 Door, left 3 1
5 Main lid handle seat, left 1 1 37 Door, right 3 1
6 Main lid handle tube 1 1 38 Lighting rod 1 1
7 Main lid handle seat, right 1 1 39 Lighting rod cover 1 1
8 Warming rack 1 1 40 Gas tank tray slide 1 2
9 Cooking grid with hole 3 3 41 Tank tray bolt 1 1
10 Flame tamer 1 4 42 Gas tank tray block piece 1 1
11 Main burner 10 4 43 Gas tank tray slide bracket, left 1 1
12
Main burner igniter wire A
1
1
44
Tank tray
1
1
12
Main
burner
igniter
wire
A
1
1
44
Tank
tray
1
1
13 Main burner igniter wire B 1 1 45 Gas tank tray slide bracket, right 1 1
14 Main burner igniter wire C 1 1 46 Electric igniter module 1 1
15 Main burner igniter wire D 1 1 47 Bottom panel 1 1
16 Main lid bracket, right 1 1 48 Swivel caster with brake 1 1
17 Burner pin assembly 1 4 49 Swivel caster 1 1
18 Main lid bracket, left 1 1 50 Door hinge bracket 1 4
19 Regulator, LP 1 1 51 Side panel, left 1 1
20 Front baffle 1 1 52 Rubber grommet 1 1
21 Igniter junction wire 1 1 53 Back panel 1 1
22 Main burner gas valve 1 4 54 Caster 1 2
23 Main manifold 1 1 55 Side panel, right 1 1
24 Side mainfold 1 1 56
Searing side burner control panel,
right
11
25 Sear burner gas valve 1 1 57 Sear burner igniter wire 1 1
26
Searing side burner flex gas
line
1 1 58 Searing side burner grease tray 1 1
27 Logo 1 1 59
Sear burner
11
28 Main control panel 1 1 60 Searing side burner bowl assembly 1 1
29 Control knob 1 5 61 Hooks 1 6
30
Bezel
1
4
62
Searing side burner end cap
1
1
30
Bezel
1
4
62
Searing
side
burner
end
cap
1
1
31 Cart frame, front 1 1 63 Sear burner cooking grid with hole 3 1
32 Door magnet 1 2 64 Searing side burner lid 1 1
10
