KitchenAid KODE300ESS - Component Access and Removal

COMPONENT ACCESS
Built-In Single and Double Wall Ovens
n
4-1
Section 4:
Component Access
This secon provides service parts access, removal,
and replacement instrucons for the “KitchenAid
Built-In Wall ovens.
How to remove the:
• Control Panel
• Exhaust Blower Motor and Fan Assembly
• Components at the back of a Double or Single
wall Oven
• Oven Shutdown Thermal Fuse from the upper
oven of a Double Oven conguraon or a
Single oven
• Oven Shutdown Thermal Fuse from the Lower
Oven of a Double Oven
• Oven Light Assembly
• Convecon Fan Motor
• Hidden Bake Element
• Probe Jack Assembly
• Oven Door
• Broil Element
• Oven Sensor
• Convecon Element
• Door Latch and Oven Light switch Assembly
Multimedia
Enhanced

Complete Component Access Video
Whenever coming across the Camera icon
throughout Secon 4, click on the ICON and
a video will play pertaining to the subject
directly below it
