KitchenAid KODE300ESS - Exhaust Blower Motor and Fan Assembly Removal

COMPONENT ACCESS
Built-In Single and Double Wall Ovens
n
4-3
REMOVING THE EXHAUST BLOWER
MOTOR AND FAN ASSEMBLY
Double oven will have both appliance manager
boards at this locaon. Upper oven control is
on the right and the lower oven control is on the
le side.
Single oven will have one appliance manager
board.
Remove electrical connecons and remove 2
mounng screws on the le side of the board.
Pull board to the le to release two mounng
tabs on the right side of the board.
The oven will need to be completely removed from
the cabinet. Remove the top control service
covers.
Remove the mounng screws and remove both
covers.
The back service cover (behind the oven) will need
to be removed. Locate the mounng screws
and remove the cover.
The blower motor and fan assembly is now
completely exposed. Remove the electrical
connecon to the motor. Remove two Blower
Assembly mounng screws from each side of
the assembly and remove the assembly.

WARNING
Electrical Shock Hazard
Disconnect power before servicing.
Failure to do so can result in death or
electrical shock.
Replace all parts and panels before operating.

