KitchenAid KODE500EBS - Accessing Oven Door and Latch

COMPONENT ACCESS
Built-In Single and Double Wall Ovens
n
4-7
REMOVING THE PROBE JACK ASSEMBLY
From the right side of the oven remove the side
insulaon cover (top front and rear service
covers are also removed).
Pull the insulaon back to expose the jack
assembly and pull (sh) the jack wiring harness
out.
REMOVING THE OVEN DOOR
It may be easier servicing the next few
components with the oven door and oven
racks removed.
Open the oven door.
At the two door hinge locaons will be a hinge
lock retainer. Li the hinge retainers all the way
to the stop posion.
Grasp the door at each side and close the door
unl it stops.
Once it is stopped, push the upper poron of the
door toward the oven cavity and the hinges will
release.
Set the door aside.
From inside the oven (right side wall) remove a nut
that mounts the jack in place.
From outside the oven remove the back service
panel and disconnect the probe electrical
connecon.
WARNING
Electrical Shock Hazard
Disconnect power before servicing.
Failure to do so can result in death or
electrical shock.
Replace all parts and panels before operating.


