KitchenAid KODE500ESS Installation Instructions

10
6. Using 2 or more people, place the oven in its upright position.
7. Go to the “Make Electrical Connection” section.
Double Ovens
The positioning of the oven feet allow a double oven to be
installed in a cutout height between 48⁷⁄₈" and 52³⁄₁₆" (124.1 cm and
132.6 cm). Refer to the following instructions to position the feet
for the size of your cabinet cutout.
Cutout Height is Between 48⁷⁄₈" 50⁷⁄₁₆" (124.1 cm and
128.1 cm)
The oven feet do not need to be installed. The oven is configured
correctly as received.
NOTE: Do not remove the spacers.
Go to the “Make Electrical Connection” section.
A. Spacers
A
A

KitchenAid KODE500ESS Specifications

General

Type	Double Oven
Fuel Type	Electric
Convection	Yes
Self-Cleaning	Yes
Control Type	Touchscreen
Color	Stainless Steel
Voltage	240 V
Brand	KitchenAid
Model	KODE500ESS
Installation Type	Built-In
Number of Ovens	2
Upper Oven Capacity	5.0 cu. ft.
Lower Oven Capacity	5.0 cu. ft.
Amperage	40 A
Warranty	1 Year Limited
Total Capacity	10.0 cu. ft.
