◆ Design specifications of KITZ optional accessories
Accessories Specification
NAMUR solenoid valves
Explosion proof
Weather proof indoor use
Weather proof outdoor use
Power supply
：AC100V／110V 50／60Hz
：AC200V／220V 50／60Hz
：DC24V
Air inlets：Rc1/4
Maximum working pressure：0.7MPa
Switch boxes
With built-in sensitive switches
With built-in proximity switches
Switch boxes with built-in sensitive switches
Resistive load ：11A AC125V／250V
：0.5A DC125V
：0.25A DC250V
Inductive load ：7A AC125/250V
Switch boxes with built-in proximity switches
Power supply ：DC10～36V
Maximum output current
（instantaneous and continuous）：200mA
Limit switches
Weather proof
Explosion proof
Weather proof ：10A－125V／250V／480V AC
：0.8A－125V／0.4A－250V DC
Explosion proof ：5A－125V／250V／480V AC
：0.8A－125V／0.4A－250V DC
Proximity switch Power supply ：20-250V AC／DC
Switching current：AC350mA／DC100mA
Air filter-regulator Working pressure：Inlet Max0.97MPa
：Outlet Max0.4～0.7MPa
Connection：Rc1/4
Speed controller Connection：Rc1/4
Maximum working pressure ：0.97MPa
Silencer Connection：Rc1/4
Maximum working pressure ：0.90MPa
Positioner Connection：Rc1/4（Pressure gauge：Rc1/8）
Supply pressure：0.3～0.7MPa
Signal pressure：0.02～0.10MPa
Signal current：4～20mA
Air consumption：20NL/min.(Max.)
[Supply pressure： 0.5MPa]
By-pass valve Connection ： Rc1/4 Maximum working pressure ：
0.7MPa
