Kjellberg FineFocus Flash 101

Questions and Answers

B
Brett HarperAug 15, 2025
What to do if the LED signal lamp is white and the 'plasma torch' is OFF on my Kjellberg FineFocus Flash 101?
- S
  Susan MedinaAug 15, 2025
  If the white LED signal lamp for the plasma torch is OFF, and there's no full cutting power, it could be due to several reasons: * The pilot arc time might be exceeding 6 seconds without current flow to the workpiece. In this case, finish after approximately 1 second. * The workpiece may not be properly connected. * The plasma gas supply might not be correct. * The current values might be too low for the material thickness. Try readjusting the current using the potentiometer.
J
Jeffery MorrisonAug 18, 2025
How to troubleshoot if the fans unit does not start in my Kjellberg FineFocus Flash 101 Welding System?
- B
  benjamin01Aug 18, 2025
  If the fans unit isn't starting, consider the following possible causes: * Ensure the emergency switch S3 (7) (detent switch) is shifted. * Check that the wire link X102 (C3-C4) (“Emergency OFF” from CNC) is plugged in. * Verify the air pressure is above 0.3 MPa. * The temperature monitor may have switched off the unit. * There might be another defect at the power source. * Ensure the protection cap on the plasma torch is present.
E
escobarjennaAug 21, 2025
What does error E39 mean on my Kjellberg FineFocus Flash 101, and how can I fix it?
- M
  Meredith BrownAug 21, 2025
  Error E39 indicates a torch cap issue. To resolve this, switch OFF the unit and then check the torch and consumables. Note that the Error LED is only cleared by turning the key switch off and on again.
T
Todd RamirezAug 25, 2025
What does error code E4 mean on my Kjellberg Welding System and how to resolve it?
- R
  Rebecca RodriguezAug 26, 2025
  Error code E4 indicates that the pilot arc time has been exceeded. If you're using a remote control, press 'FB OFF'. If you're using CNC, stop ON.
M
mburnettAug 28, 2025
What does error E31 mean on my Kjellberg FineFocus Flash 101 Welding System, and how do I fix it?
- D
  Denise BarrettAug 28, 2025
  Error E31 indicates an issue with the current relay workpiece K1. To address this, switch OFF the unit and then check the torch and consumables.
C
clopezSep 1, 2025
What to do if I get error E6, a plasma main arc interruption, on my Kjellberg Welding System?
- D
  Donna WebbSep 1, 2025
  Error E6 signifies an arc interruption during cutting (main source). Finish after approximately 1 second.
M
Marvin ThompsonSep 4, 2025
What does error E21 mean on my Kjellberg FineFocus Flash 101 Welding System and how to fix it?
- R
  Ruben HillSep 4, 2025
  Error E21 indicates a problem with the current relay workpiece K1. If you're using a remote control, press 'FB OFF'. If you're using CNC, stop ON. If the problem persists, inform the service.
S
Stephanie Ballard MDSep 7, 2025
What does error E8 mean on my Kjellberg FineFocus Flash 101 Welding System, and how can I resolve it?
- K
  Kimberly JonesSep 7, 2025
  Error E8 indicates that the maximum gas test period has been exceeded. To resolve this, switch the tumbler switch from 'gas test' to 'OFF'.
B
Belinda BakerSep 12, 2025
What does error code E9 mean on my Kjellberg FineFocus Flash 101 and what should I do?
- R
  Rachel HuntSep 12, 2025
  Error E9 indicates a plasma arc interruption during ignition, meaning the main arc is not formed. To solve this, finish after approximately 1 second.
