45
EN
The duct can be compressed to 270 mm minimum and extended to 1500 mm
maximum. It is better to keep the duct length to a minimum length.
Stretching or bending the duct excessively will affect the cooling eciency. (As the
following g. shows)
Do not! Yes!
Without installation
If the unit does not have the window slider kit and wall exhaust, and the Adaptor
B is like this ,as shown in Fig H. You can open the window slightly and position as
shown in Fig I.
H I
To Next Page
