27
EN
Installation under a wall cabinet
Drill a 130 mm diameter hole and four 3.5 mm diameter holes as shown below.
Note: If your cooker hood works in recirculation mode, it is not necessary to drill a
hole!
Fasten the cooker hood to the wall cabinet using the 4 screws. Check the correct position
of your xings, position the cooker hood and tighten the screws.
