Installation on the wall
1 Drill two 10 mm diameter holes in the wall at a distance of 538 mm, as shown in
the picture. Make sure that the hood is directly above the hob.
2 Insert two of the supplied plastic plugs into the holes.
3 Insert two screws into both plastic plugs and allow the screws to protrude about
3mm from the wall when tightening.
4 Hang the cooker hood on the two screws and mark the lower two screw positions.
5 Remove the cooker hood, drill the lower two screw holes and insert the remaining
two plastic dowels.
6 Mount the hood on the upper screws, insert the lower screws and tighten all screws.
SWITCHES AND FUNCTIONS
Motor on/off
Low speed
Medium speed
High speed
Light on/off
