1. The distance between the cooking surface and the lowest edge of the cooker
hood must be at least 65 cm (see picture 1).
2. Once the height is dened, install the anchoring in the appropriate place. To
do this, you must rst drill holes (you will need a drill, suitable drill bits, dowels
and screws) and then x the anchorage to the wall with the screws. After the
anchoring is xed, use the similar procedure to attach the internal clamp for
the replace facing (see Figure 2). Please pay attention to the correct distance
(please measure the distance), because the replace facing will be xed to the
bracket later.
3. Please x the outside clamp for the replace facing to the outside of the facing
and check if the inside replace facing is free to move in height. Next, install
the pipe connection and the chimney facing on the hood. Refer to Figure 3.
4. Place the hood on the anchorage (see Figure 4). 5.
5. Set the correct height of the inner chimney facing so that the brackets match
and x them. After that you can x the hood with the safety screws(see picture
5).
Note: Please note that the two safety caps are located on the back of the casing.
1 2
Inside chimney bracket
Hook
