27
EN
Temporary installation
1. Attach both ends of the exhaust hose to the square xing clip and at xing clip.
2. Insert the square xing clip into the opening on the back of the fan.
3. Place the other end of the exhaust hose on a nearby sill.
Installation of the window slider set (not included/separately available)
Sash sets are usually installed horizontally and vertically. Check the minimum and
maximum window sizes as shown in the gure below.
Window size
min. 67. 5 cm
max. 123 cm
Function of the inner water tank
The inner water tank has a safety function that controls the water level. When the water
level reaches a certain level, an indicator will light up to indicate that the water tank is
full (If the water pump is damaged when the water tank is full, remove the rubber plug
on the bottom of the unit to drain all water.)
