Klein Tools IR1 - Feature and LCD Details; Component Identification; LCD Symbol Explanations

4
3
1
2
6
1.
LCD Display
2.
Trigger
3.
Battery Compartment Door
4.
IR Temperature Sensor
5.
Targeting Laser
6.
°F/°C Switch (Behind
Battery Compartment Door)
NOTE: There are no
user-serviceable parts
inside meter.
FEATURE DETAILS
ENGLISH
A.
Temperature Reading
B.
Targeting laser active
C.
Data Hold
D.
Battery level indicator
E.
Active temperature scale
SYMBOLS ON LCD
4
5
Front
B DC
E
A
