Dwg Name: VDV526-200-1390397ART
Dwg No: 1390397
ECO No: 041006 Rev: B
Pkg Dwg Ref: 1290186
Finish Coat Requirements: N/A
3
FIG. 1
FIG. 2
FIG. 3
A
C
B
TESTER PORTS, BUTTONS & DISPLAY
TESTER (FIG. 1 & FIG. 2)
FIG 1 - RJ45 shielded jack FIG 2 - Removable docked remote with Shielded
RJ45 jack
BUTTONS (FIG. 3)
Test Button
A
performs wire map test on RJ45 terminated cable.
Tone Button
B
transmits analog tones on conductor wires of RJ45 terminated
cables. Button also cycles through available tone cadences and conductor wire
selection options.
Power/Backlight Button
C
turns unit on or off, turns backlight on or off.
VDV526-200-1390397ART.indd 3VDV526-200-1390397ART.indd 3 7/30/21 8:46 AM7/30/21 8:46 AM
