ENGLISH
GENERAL SPECIFICATIONS
The Klein Tools LAN Scout™ Jr. 2 is a portable data cable tester. It tests and
troubleshoots RJ45 terminated cables and provides tone generation for
cable tracing.
•
Dimensions: 5.3" x 2.4" x 1.2" (13.5 x 6.1 x 3.0 cm)
•
Weight: 4.0 oz. (115 grams) with battery and remote
•
Operating temperature: 0°C to 50°C / 32°F to 122°F
•
Storage temperature: -20°C to 60°C / -4°F to 140°F
•
Humidity: 10% to 90%, non-condensing
•
Maximum Voltage between any two connector pins without damage:
RJ Jack: 66V DC or 55V AC
•
Battery Life typical: 2x AAA Alkaline batteries Standby: 3 years Active: 80 hours
•
Cable types: Shielded or Unshielded; Cat-7, Cat-6/6A, Cat-5E, Cat-3
•
Maximum Cable Length: 2000 feet (610 meters)
•
Minimum Cable Length for Split pair Detection: 1.5 feet (0.5 meters)
WARNINGS
To ensure safe operation and service of the tester, follow these instructions.
Failure to observe these warnings can result in severe injury or death.
•
The LAN Scout™ Jr. 2 is designed for use on unenergized cabling systems.
Connecting the LAN Scout™ Jr. 2 to live AC power may damage it and pose a
safety hazard for the user.
•
Improperly terminated RJ plugs have the potential to damage the jacks on the
LAN Scout™ Jr. 2. Visually inspect an RJ plug before inserting it into the tester.
Plugging 6-position plugs into the 8-position jack on the tester has the potential
to damage the outer-most contacts of the jack unless the plug is specifically
designed for that purpose.
WARNING SYMBOLS ON TESTER
Warning or Caution
Always wear approved eye protection
Do NOT use on energized circuits
Read instructions
Conformité Européenne - Conforms with European
Economic Area directives
UKCA: UK Conformity Assessment
This symbol indicates that equipment and its accessories
shall be subject to a separate collection and correct disposal
