Tow Cable 2-5
2.5.11 Pressure Sensor (Optional)
Pressure range: Selectable
Accuracy: ±0.10%
2.6 Tow Cable
Type: Polyurethane jacketed coaxial, Kevlar
reinforced
Conductors: Coaxial copper
Diameter (OD): 1.156 cm (0.455 in.)
Breaking strength: 2270 kg (5000 lb)
Working load: 454 kg (1000 lb)
Operational length: 3000 m maximum
Voltage rating: 600 VDC
Termination: Stainless steel shackle at towfish end
