Klein 3900 Series - Figure 5-5: Inside the Cover of the Splashproof TPU Case

5-4 CHAPTER 5 Splashproof TPU
Series 3900 Sonar System Operations and Maintenance Manual 11214510, Rev. 02
Figure 5-4:
Splashproof TPU Connector Panel
Figure 5-5: Inside the Cover of the Splashproof TPU Case
View ports
Connector panel
Connector panel
Baffle
Baffles
Wireless
router
Antenna
Fan
