5-6 CHAPTER 5 Splashproof TPU Series 3900 Sonar System Operations and Maintenance Manual 11214510, Rev. 02
Figure 5-6: Front Panel of VME Chassis inside Splashproof TPU
COM1
DEBUG
LAN
TRIG 1
CABLE
COM2
Inverter
Demultiplexer board
CPU board
Low voltage
power supply
VOLTAGE SELECT
switch (See CAUTIONS
on page 5-10.)
VME chassis
