Klipsch BAR 48 Firmware Update Instructions

RE-PAIRING SUBWOOFER (After Firmware Update)
BAR 48
Press and hold the pairing button on the back of
the subwoofer for 3 seconds until the blue LED
begins flashing rapidly.
3
Press and hold the pairing button on the back of
the Sound Bar for 3 seconds until the source LED
begins flashing.
4
Ensure the subwoofer is plugged in.
1 2
Front Volume LED’s will show the Volume at 3.
100-240 V~1A
100-240 V~1A
Wait until the source indicator on the Sound Bar
stops flashing and glows solid. This indicates a
successful connection with the subwoofer.
5
Unplug the Power Cable on the back of the
subwoofer and wait until the blue LED is
COMPLETLEY off.
6
(Will glow blue)
(Will begin flashing)
(Will stop flashing & glow solid)
100-240 V~1A
Problems or questions? Submit a request!
Troubleshooting/Service

Klipsch BAR 48 Specifications

General

RMS rated power	440 W
Audio output channels	3.1 channels
Subwoofer type	Active subwoofer
Subwoofer included	Yes
Subwoofer location	Separate
Subwoofer connectivity	Wireless
Woofer diameter (subwoofer)	8 \
Tweeter diameter	25.4 mm
Mid-range driver diameter	76.2 mm
Number of tweeter drivers	3
Number of mid-range drivers	4
Tweeter diameter (imperial)	1 \
Mid-range driver diameter (imperial)	3 \
HDMI ports quantity	-
Connectivity technology	Wired & Wireless
Digital audio optical in	1
Product color	Black
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz

Weight and Dimensions

Depth	86 mm
Width	1211 mm
Height	73 mm
Cord length	1.5 m
Soundbar weight	- g
Subwoofer width	302 mm
Subwoofer height	410 mm
