Klipsch POWERGATE User Manual

11
CONNECTIONS - WIFI NETWORK (NOTE: PLAY-FI REQUIRES USE OF AN 802.11N WIRELESS ROUTER OR BETTER)
CONNEXIONS - RÉSEAU WI-FI (REMARQUE : PLAY-FI NÉCESSITE L’UTILISATION D’UN ROUTEUR SANS FIL 802.11N OU MIEU) • CONEXIONES - RED WI-FI (NOTA: PLAY-FI REQUIERE UN ROUTER
INALÁMBRICO 802.11N O MÁS RECIENTE) • ANSCHLÜSSE – WLAN (HINWEIS: PLAY-FI ERFORDERT DIE VERWENDUNG EINES WLAN-ROUTERS NACH DER NORM 802.11N ODER BESSER) •
CONNESSIONI – RETE WI-FI (NOTA: PLAY-FI RICHIEDE L’USO DI UN ROUTER WIRELESS 802.11N O SUPERIORE) • CONEXÕES - REDE WIFI (OBSERVAÇÃO: O PLAY-FI REQUER O USO DE UM ROTEADOR SEM
FIO 802.11N OU MELHOR) • 连接 - WIFI 网络 备注： PLAY-FI 需要使用 802.11N 或性能更佳的无线路由器
100-200V/200-240V~
50/60Hz, 200W
ANALOG OUT
OPTICAL IN
WiFi
SETUP
USB AUDIO SERVICE INOUT
ANALOG IN
LL RR
PHONO
LINE
LSUB
AUX
GNDR
100-200V/200-240V~
50/60Hz, 200W
ANALOG OUT
OPTICAL IN
WiFi
SETUP
USB AUDIO SERVICE INOUT
ANALOG IN
LL RR
PHONO
LINE
LSUB
AUX
GNDR
DOWNLOAD
KLIPSCH STREAM
LED
PULSING
SLOWLY
43
WPS
2
LAUNCH APP
AND FOLLOW
THE INSTRUCTIONS
1
2
WIFI SETUP WIFI SETUP
HOLD 10 SECONDS
MAINTENEZ ENFONCÉ PENDANT 10 SECONDES
MANTENGA OPRIMIDO 10 SEGUNDOS
10 SEKUNDEN GEDRÜCKT HALTEN
TENERE PREMUTO PER 10 SECONDI
MANTER PRESSIONADO POR 10 SEGUNDOS
按住 10 秒
HOLD 4 SECONDS
1
USBSETUP
LINE IN LINE OUT
USBSETUP
LINE IN LINE OUT

Klipsch POWERGATE Specifications

General

Amplifier class	D
Frequency range	20 - 20000 Hz
Audio output channels	2.0 channels
Peak power per channel	100 W
Signal-to-Noise Ratio (SNR)	90 dB
Total Harmonic Distortion (THD)	0.08 %
Dynamic power per channel (6 Ohm)	75 W
RMS power output per channel (2 Ohm)	50 W
Pre out port	Yes
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	2
Digital audio optical in	1
AC input voltage	110-240 V
Purpose	Home
Product color	Black
Volume control	Rotary
Cables included	Audio (3.5mm), TOSLINK Digital Optical, USB
Connectivity technology	Wired & Wireless

Weight and Dimensions

Depth	152.4 mm
Width	254 mm
Height	63.5 mm
Weight	1360 g
