Klipsch RW-12 User Manual

RW-12 PARTS LIST
PAR
T
DESCRIPTIO
N
KLIPSCH PT #
Q704,Q710 TRANS, NPN 150V 0.6A 2N5551TR
Q703,Q709 TRANS, PNP 150V 0.6A 2N5401TR
Q105,Q111 MOSFET, IRF9540 TO220AB
Q106,Q112 MOSFET, IRF530 TO220 (IR ONLY)
Q100 JFET, N-CH J113 TO92 TR
R718,R719,R738,R739 RES, CF 330R 1/4W 5%
R709,R710,R711,R712,R729,R730,R731,R732 RES, CF 510R 1/4W 5%
R120,R121,R140,R141 RES, MF 1K00 1/4W 1%
R102,R103,R104,R105,R106,R107,R127,R128 RES, MF 10K0 1/4W 1%
R713,R717,R733,R737 RES, MF 2K00 1/4W 1%
R715,R716,R735,R736 RES, MF 3K92 1/4W 1%
R101 RES, MF 20K0 1/4W 1%
R126,R146 RES, MF 64K9 1/4W 1%
R122,R123,R142,R143 RES, MF 22R 0.6W 1% FLAMEPROOF
R714,R734 POT, 500R 8MM HOR TOP ADJ/COVR
R111,R112 RES, MO 150R 3W 5% 2W BODY
R109,R110 RES, MO 0R1 2W 5% 1W BODY
U100 OPAMP, QUAD 14P DIL TL074CN
U102 VREG, +15V 500MA LM7815CT
U103 VREG, -15V 500MA LM7915CT
PANEL
POWER SOCKET
IEC/FUSE COMBO SOCKET
FUSE (120V) FUSE, T3.15A/250V, 5X20MM, SLOW BLO
FUSE (230V) FUSE, T1.6A/250V, 5X20MM, SLOW BLO
KNOBS POT, KNOB CR00-15MB-16H
118814
SWITCH ROCKER TV5 C/W TERM
HIGH LEVEL + SINGLE BINDING POST RED
118810
HIGH LEVEL - SINGLE BINDING POST BLK
118811
CABLES
VOLUME CONTROL FEM-FEM HARNESS 3P 40"
LED FEM-LED R/G 4" 2PIN 3M
POWERSUPPLY TO LINEAR
LINEAR TO FEATURE
CNCTR, FEM-FEM HARNESS 8P 9"
9
