RW-12 PARTS LIST
PAR
T
DESCRIPTIO
N
KLIPSCH PT #
R203,R204,R210 RES, MO 0R1 2W 5% 1W BODY
U200
BASH CONTROLLER BOAR
D
SUBASSY, BASH CNTRLR MULTI
C1 CAP, CA 1000PF 100V 10%
C6 CAP, CA 47PF 50V 10%
C3 CAP, F 2200PF 100V 5% 5MMLS
D1,D2,D3,D4 RECT, 100mA 75V SIGNAL 1N4148T
Q2,Q4 TRANS, NPN 40V .6A TO92 2N4401
Q1,Q3 TRANS, PNP 150V 0.6A 2N5401TR
R6,R9 RES, CF 10K 1/8W 5%
R12 RES, MF 2K32 1/4W 1%
R2,R3 RES, MF 1K00 1/8W 1%
R5 RES, MF 1K50 1/8W 1%
R10,R11 RES, MF 475R 1/8W 1%
R1 RES, MF 6K81 1/8W 1%
R4 RES, MF 3K65 1/8W 1%
U1 PWM, 8PIN DIP UC3842N
U402 PDC CONTROLLER BOARD SUBASSY, PDC CNTRLR 1014
C11 CAP, CA 4700PF 100V 10%
C1,C2 CAP, F 3300PF 63V 5% 5MMLS
D11 RECT, 1A2 60V DIAC HT60TR
D12 RECT, 100mA 75V SIGNAL 1N4148T
D13,D14 RECT, 100MA 200V SIGNAL 1N3070
Z1,Z2 ZENER, 500MW 15V 5% 1N5245B
Q11 TRANS, PNP TO92 MPSA92TR
R12 RES, MF 1K00 1/4W 1%
R1,R4 RES, MF 392R 1/4W 1%
R2,R3,R5,R6 RES, MF 750R 1/4W 1%
R11,R13,R14 RES, MF 200K 1/4W 1%
FEATURE BOARD
C1,C107
NOT INSTALLED
C124 CAP, C 470PF 1KV 10% .2LS TR
C126,C128 CAP, CA 1000PF 100V 10%
C125 CAP, CA .1UF 100V 20%
C101,C108,C110,C122 CAP, CA 100PF 100V NPO 10%
C118,C127 CAP, E 47UF 50V 20% 5MMLS
C123 CAP, E 22UF 50V 20% 5X11 5MMLS
C129,C130 CAP, E 4.7UF 50V 85D 5X11 5MML
C102,C109,C113 CAP, E 22UF 35V BP 8X11 5MMLS
C103,C105,C111,C112,C114,C116,C117 CAP, F .1UF 63DC 5% 5MMLS
C121 CAP, F .01UF 100V 5% 5MMLS
C104,C106,C115 CAP, F .047UF 100V 5% 5MMLS
D100,D101,D102,D103,D104,D105,D106,D107,D108,D109,D110,
D111
RECT, 100mA 75V SIGNAL 1N4148T
Z100,Z101,Z102,Z103 NOT INSTALLED
Z104 ZENER, 500MW 7.5V 5% 1N5236B
Q1,Q2 JFET, N CHAN J108 TO92
R111,R116,R125,R139,R144,R175 NOT INSTALLED
R178 RES, CF 1K0 1/2W 5%
R174 RES, CF 150R 1/4W 5%
R148 RES, CF 100K 1/4W 5%
7
