Klipsch RW-12 User Manual

RW-12 PARTS LIST
PAR
T
DESCRIPTIO
N
KLIPSCH PT #
POWER SUPPLY BOARD
T400 XFMR, POWER 100V HC TRAN ETD39
L402 IND, CM CHOKE 1.8mH
L200 IND, POWER 16T 19.2UH W/BOBBIN
C430,C431,C433,C434 NOT INSTALLED
C200,C208 CAP, CA 470PF 100V 5%
C202 CAP, CA 1000PF 100V 10%
C204 CAP, CA 2200P 100V 10%
C205,C206,C209,C407,C421,C422,C424 CAP, CA .1UF 50V 20%
C207 CAP, CA .01UF 100V 20%
C413,C414,C435,C436 CAP, C 1UF 100V 20% .2LS
C417 (120V) CAP, CY1 1500PF 250V 20% .4LS
C417 (230V) CAP, CY1 4700PF 250V 20% .4LS
C418,C419 CAP, E 47UF 50V 20% 5MMLS
C427,C428 CAP, E 470UF 200V 20% 22X40
C426 CAP, E 22UF 50V 20% 5X11 5MMLS
C412 CAP, E 1000UF 100V 18X40
C415,C416 CAP, F .1UF 250V 10% 10MMLS
C400,C432 CAP, FX .22UF 250V 10% 22MMLS
C203 CAP, F 6.8UF 250V 5% 27.5MMLS
C403,C429 CAP, F .1UF 250V 10% 5MMLS
D400 RECT, 6A 400V BRIDGE PRETRIM
D407 RECT, 16A 200V CATHODE FEP16DT
D203,D408 RECT, 1A 100V FAST REC 1N4934
D405,D406 RECT, 1A 600V ULTRAFAST MUR160
D200 RECT, 15A 200V ULTRA MUR1520
D201 RECT, 100mA 75V SIGNAL 1N4148T
Z405 ZENER, 500MW 16V 5% 1N5246B
R400 SURGISTOR, 10R 2A CL-110
Z400 VARISTOR, 275V 100J .6W
Q201 TRANS, PNP 40V .6A TO92 2N4403
Q403,Q405 TRANS, NPN 40V .6A TO92 2N4401
Q404 TRANS, NPN 150V 0.6A 2N5551TR
Q401,Q402 MOSFET, IRF740 TO220AB IR ONLY
Q200 MOSFET, IRF540 TO220AB IR ONLY
R422,R423 NOT INSTALLED
R426 RES, CF 160K 1/4W 5%
R401,R414 RES, MF 100K 1/4W 1%
R427,R428 RES, MF 100R 1/4W 1%
R214 RES, MF 47R5 1/4W 1%
R412 RES, MF 4K75 1/4W 1%
R215 RES, MF 90R9 1/4W 1%
R200 RES, MF 16K5 1/4W 1%
R416 RES, MF 49K9 1/4W 1%
R415 RES, MF 8K45 1/4W 1%
R202 RES, MF 8K66 1/4W 1%
R413,R421 RES, MF 10R 0.6W 1% FLAMEPROOF
R209 RES, MF 22R 0.6W 1% FLAMEPROOF
R201 RES, MF 2K26 1/4W 1%
R206 RES, MF 100R 0.6W 1% FLAMEPRF
R211 RES, MO 330R 2W 5%
R425 RES, MO 47K 1W 5%
6
