Klipsch SW12-I User Manual

Klipsch Subwoofer Amplifier Service Manual KSAMM-002a
SW12-I PARTS LIST(continued)
PART
VALUE/PART NUMBER KLIPSCH PART #
C36, C37, C39, C40 330pF
C6 4.7µF 25V Electrolytic
C55 10µF 63V Electrolytic
C18 10µF 25V Electrolytic
C7 .0027µF
C8, C9 1µF
D18 1N914B
D5, D6 1N4752A Zener
U1 MC4741 118744
U2, U4 MC1458N 118743
U5 NE570 118745
U6 LM393 118742
Q1, Q2, Q11 MPS8099 118735
Q28 2N3906 118728
Q3, Q4, Q12 MPS8599 118736
Q5 MPSW56 118738
Q6 MPSW06 118737
Q7, Q9 2SA1306B 118730
Q8, Q10 2SC3298B 118732
R100, R101, R102, R103, R110, R111, R112, R113
.47: 5WATT
R114
4.7: 3WATT
R115
1: 3WATT
R116, R121, R126, R130 10K
R117, R119 56K
R118 22K
R120
390: 1WATT
R122, R123 100K
R125
68:
R131 10K Variable
R135 1.8K
R136 6.8K
R76, R77
15: 1WATT
R82
150:
R83
100:
R84
100: Variable
R87, R88, R89, R90 1.5K 5WATT
R91, R92
51:
R93
22.1:
R94, R95, R98, R99, R104, R105, R108, R109
1.2: 1/2WATT
C21, C22 1000µF 35V Electrolytic
C23, C24 1µF 25V Electrolytic
C28, C31 470µF 100V Electrolytic
C43 100µF 10V Electrolytic
C44, C45, C46, C47 4700µF 100V Electrolytic
C48 .1µF
C49 33µF 50V Electrolytic
C50 4.7µF 50V Electrolytic
C52 330µF 16V Electrolytic
Page 10

Klipsch SW12-I Specifications

General

Brand	Klipsch
Model	SW12-I
Category	Amplifier
Language	English
