Klipsch Subwoofer Amplifier Service Manual KSAMM-002a
SW12-I PARTS LIST
PART VALUE/PART NUMBER KLIPSCH PART #
LEVEL CONTROL 10K VARIABLE
LOWPASS ADJUST 50K VARIABLE, DUAL
PHASE ADJUST 100K VARIABLE
R1, R2, R3, R128, R137, R138 15K
R12, R11 47K
R13, R35, R36, R133, R134 22K
R132 2.2 Meg
R139 39K
R14, R21 6.65K
R15 20K
R16, R18, R19, R40, R41, R127 10K
R17 5.23K
R20 2K
R22 30.1K
R28, R29 220K
R30, R34, R50 10K VARIABLE
R31, R32, R37 100K
R33, R42, R68, R71
100:
R38 43K 2%
R39 180K 2%
R43, R44 10K 2%
R6, R8, R46 4.7K
R47, R53 4.3K 3WATT
R9
0:
R49 33.2K
R51, R67 1K
R54, R62 1.1K
R55, R63
300:
R56, R61 11.5K
R57, R58, R59, R60
220:
R6, R8
510: 2WATT
R64, R69
511:
R65, R70, R73, R75
22.1:
R66 39.2K
R72, R74 2.7K 3WATT
R10 91K
R45
1M:
R7
47:
R4, R5 300K
C1, C2 .22µF
C10, C27, C30 .1µF
C11 .12µF
C15, C53 .047µF
C16, C17, C19 1µF 25V Electrolytic
C20 .01µF
C5 .001µF
C29 2.2µF
C3, C4 150µF 100V NON-POLAR
C32, C33 470µF 50V Electrolytic
C34, C35 22pF
