Klipsch SW12-I User Manual

Klipsch Subwoofer Amplifier Service Manual KSAMM-002a
SW12-I PARTS LIST(continued)
PART
VALUE/PART NUMBER KLIPSCH PART #
C54 10µF 25V Electrolytic
C56 .1µF 125Vac
D1, D2, D3, D4, D11, D12 1N4002
D13, D14, D15, D16, D17 1N914
Q15, Q18 MJF15030 118733
Q16, Q17, Q19, Q20 2SC3281 118731
Q21, Q24 MJF15031 118734
Q22, Q23, Q25, Q26 2SA1302 118729
Q27 MPSA06
U11 UPC1237 118746
U12 MC1458 118743
U7 7815 118739
U9 7915 118740
L1 2µH
F2, F3 JUMPER
RLY1 AROMAT J51E-12 (Relay)
RCA PANEL
SPEAKER INPUT JACKS
TRANSFORMER PW-6582 118721
SW2 (Power)
F1 5 Amp 250Vac Slow Blow 118348
TH1 (Thermal protection) ASAH US-602S
BR1 GBPC 3502
DUAL VOLTAGE TRANSFORMER PW-6661 118725
DUAL VOLTAGE SWITCH 115 to 230
CAPACITOR (DUAL VOLTAGE MODEL) .047µF 300V
Page 11

Klipsch SW12-I Specifications

General

Brand	Klipsch
Model	SW12-I
Category	Amplifier
Language	English
