AURA 80, CLASS 90, AURA 120, REA 100 PELLET-BURNING STOVE
EN - Rev. 1.6
PCB PARAMETERS
The parameters stored on the PCB are essential for the correct operation.
The following parameters are already stored during the testing of the appliance directly in the factory; these parameters
are the result of special tests using several types of pellets and must not be changed without the authorisation of Klover
srl so as not to impair the operation of the appliance.
The company shall not be held liable for any damage caused by the incorrect entry of parameters.
Parameter tables for AURA 80 AIR / CLASS 90 AIR
Parameters “CLEANER CALIBRATIONS” - Mod. A80 / CL90 (L09_161018)
Parameter
Menu level
Description
Display
Measurement
Value field
Database
o1
Pr51
M10 – 01 – 01
ON time for brazier cleaning gear motor
CLEANING TIME
Seconds
0 – 120”
13
Pr52
M10 – 01 – 02
Time from switching off after which the brazier cleaning takes place
CLEANER DELAY
Minutes
1 – 15‘
6
Pr53
M10 – 01 – 03
Time from switching on after which the brazier cleaning takes place
CLEANER STAND-BY
Hours
1 – 24
9
Parameters “DUCTING CALIBRATIONS” - Mod. A80 / CL90 (L09_161018)
Parameter
Menu level
Description
Display
Measurement
Value field
Database
o1
Pr55
M10 – 03 – 01
Enable ducting function
ENABLE DUC.
Off / Mode
Off
S1 – S2 – S1+2
T1 – T2 – T1+2
A1 – A2 – A1+2
Off
Pr56
M10 – 03 – 02
Allows for choosing whether the ducted air fans can be switch “OFF”.
OFF CANALIS-
On / Off
On / Off
Off
Pr57
M10 – 03 – 03
Heat exchanger 2 speed (ducting 1) in power 1 work phase
SPE. DUC. 1 – P.1
Volt
65 – 225
65
Pr58
M10 – 03 – 04
Heat exchanger 2 speed (ducting 1) in power 2 work phase
SPE. DUC. 1 – P.2
Volt
65 – 225
65
Pr59
M10 – 03 – 05
Heat exchanger 2 speed (ducting 1) in power 3 work phase
SPE. DUC. 1 – P.3
Volt
65 – 225
65
Pr60
M10 – 03 – 06
Heat exchanger 2 speed (ducting 1) in power 4 work phase
SPE. DUC. 1 – P.4
Volt
65 – 225
65
Pr61
M10 – 03 – 07
Heat exchanger 2 speed (ducting 1) in power 5 work phase
SPE. DUC. 1 – P.5
Volt
65 – 225
65
Pr62
M10 – 03 – 08
Heat exchanger 3 speed (ducting 2) in power 1 work phase
SPE. DUC. 2 – P.1
Volt
65 – 225
65
Pr63
M10 – 03 – 09
Heat exchanger 3 speed (ducting 2) in power 2 work phase
SPE. DUC. 2 – P.2
Volt
65 – 225
65
Pr64
M10 – 03 – 10
Heat exchanger 3 speed (ducting 2) in power 3 work phase
SPE. DUC. 2 – P.3
Volt
65 – 225
65
Pr65
M10 – 03 – 11
Heat exchanger 3 speed (ducting 2) in power 4 work phase
SPE. DUC. 2 – P.4
Volt
65 – 225
65
Pr66
M10 – 03 – 12
Heat exchanger 3 speed (ducting 2) in power 5 work phase
SPE. DUC. 2 – P.5
Volt
65 – 225
65
Parameters “VARIOUS CALIBRATIONS” – Mod. A80 / CL90 (L09_161018)
Parameter
Menu level
Description
Display
Measurement
Value field
Database
o1
Pr38
M10 – 04 – 01
Re-ignition block
RE-IG BLOCK.
Minutes
0 – 10
5
Pr39
M10 – 04 – 02
Time to consider the appliance off
OFF TIME
Minutes
0 – 20
10
Pr40
M10 – 04 – 03
Pre-loading time in ignition
PRE-L IGNITION
Seconds
0 – 255
210
Pr41
M10 – 04 – 04
Stand-by time after pre-loading
STAND-BY AFTER
PRE-L.
Seconds
0 – 255
230
Pr42
M10 – 04 – 05
Extractor speed in pre-loading phase
SPE. F.GAS PRE.
RPM
350 – 2800
2100
Pr43
M10 – 04 – 06
Temperature Delta on “SET ROOM” for automatic switching on/off
DELTA ON-OFF
°C
0.0 – 10.0
1.0
Pr44
M10 – 04 – 07
Automatic switch-off delay (timer after reaching “SET ROOM”)
DEL. OFF AUTO
Minutes
2 – 120
10
Pr45
M10 – 04 – 08
Power change delay
DEL. POW. CHANGE.
Seconds
0 – 240
60
Pr46
M10 – 04 – 09
Speed of heat exchanger 1 (primary) during switching off
SPE. AIR OFF
Volt
65 – 225
225
Pr47
M10 – 04 – 10
Keypad lock enable
KEY LOCK
On – Off
On – Off
Off
Pr48
M10 – 04 – 11
Time after which an alarm is triggered in the event of a blackout
BLACK OUT TIME
Seconds
0 – 60
30
Pr49
M10 – 04 – 12
Time after which the alarm “NO PELLET” goes if“PELLET RESERVE”
RESERVE ALARM
Minutes
1 – 180
60
Pr50
M10 – 04 – 13
Enable pellet level sensor (on prepared models only)
PELLET RESERVE
On – Off
On – Off
Off
