klover CLASS 90 - Parameter Tables for Aura 120

51
AURA 80, CLASS 90, AURA 120, REA 100 PELLET-BURNING STOVE
EN - Rev. 1.6
Parameter tables for AURA 120
Parameters “CLEANER CALIBRATIONS” - Mod. A120 (L09_161018)
Parameter
Menu level
Description
Display
Measurement
Value field
Database
o3
Pr51
M10 – 01 – 01
ON time for brazier cleaning gear motor
CLEANING TIME
Seconds
0 – 120”
13
Pr52
M10 – 01 – 02
Time from switching off after which the brazier cleaning takes place
CLEANER DELAY
Minutes
1 – 15‘
6
Pr53
M10 – 01 – 03
Time from switching on after which the brazier cleaning takes place
CLEANER STAND-BY
Hours
1 – 24
9
Parameters “DUCTING CALIBRATIONS” - Mod. A120 (L09_161018)
Parameter
Menu level
Description
Display
Measurement
Value field
Database
o3
Pr55
M10 – 03 – 01
Enable ducting function
ENABLE DUC.
Off / Mode
Off
S1 – S2 – S1+2
T1 – T2 – T1+2
A1 – A2 – A1+2
Off
Pr56
M10 – 03 – 02
Allows for choosing whether the ducted air fans can be switch “OFF”.
OFF CANALIS-
On / Off
On / Off
Off
Pr57
M10 – 03 – 03
Heat exchanger 2 speed (ducting 1) in power 1 work phase
SPE. DUC. 1 – P.1
Volt
65 – 225
65
Pr58
M10 – 03 – 04
Heat exchanger 2 speed (ducting 1) in power 2 work phase
SPE. DUC. 1 – P.2
Volt
65 – 225
65
Pr59
M10 – 03 – 05
Heat exchanger 2 speed (ducting 1) in power 3 work phase
SPE. DUC. 1 – P.3
Volt
65 – 225
65
Pr60
M10 – 03 – 06
Heat exchanger 2 speed (ducting 1) in power 4 work phase
SPE. DUC. 1 – P.4
Volt
65 – 225
65
Pr61
M10 – 03 – 07
Heat exchanger 2 speed (ducting 1) in power 5 work phase
SPE. DUC. 1 – P.5
Volt
65 – 225
65
Pr62
M10 – 03 – 08
Heat exchanger 3 speed (ducting 2) in power 1 work phase
SPE. DUC. 2 – P.1
Volt
65 – 225
65
Pr63
M10 – 03 – 09
Heat exchanger 3 speed (ducting 2) in power 2 work phase
SPE. DUC. 2 – P.2
Volt
65 – 225
65
Pr64
M10 – 03 – 10
Heat exchanger 3 speed (ducting 2) in power 3 work phase
SPE. DUC. 2 – P.3
Volt
65 – 225
65
Pr65
M10 – 03 – 11
Heat exchanger 3 speed (ducting 2) in power 4 work phase
SPE. DUC. 2 – P.4
Volt
65 – 225
65
Pr66
M10 – 03 – 12
Heat exchanger 3 speed (ducting 2) in power 5 work phase
SPE. DUC. 2 – P.5
Volt
65 – 225
65
Parameters “VARIOUS CALIBRATIONS” – Mod. A120 (L09_161018)
Parameter
Menu level
Description
Display
Measurement
Value field
Database
o3
Pr38
M10 – 04 – 01
Re-ignition block
RE-IG BLOCK.
Minutes
0 – 10
5
Pr39
M10 – 04 – 02
Time to consider the appliance off
OFF TIME
Minutes
0 – 20
10
Pr40
M10 – 04 – 03
Pre-loading time in ignition
PRE-L IGNITION
Seconds
0 – 255
215
Pr41
M10 – 04 – 04
Stand-by time after pre-loading
STAND-BY AFTER
PRE-L.
Seconds
0 – 255
230
Pr42
M10 – 04 – 05
Extractor speed in pre-loading phase
SPE. F.GAS PRE.
RPM
350 – 2800
2300
Pr43
M10 – 04 – 06
Temperature Delta on “SET ROOM” for automatic switching on/off
DELTA ON-OFF
°C
0.0 – 10.0
1.0
Pr44
M10 – 04 – 07
Automatic switch-off delay (timer after reaching “SET ROOM”)
DEL. OFF AUTO
Minutes
2 – 120
10
Pr45
M10 – 04 – 08
Power change delay
DEL. POW. CHANGE.
Seconds
0 – 240
60
Pr46
M10 – 04 – 09
Speed of heat exchanger 1 (primary) during switching off
SPE. AIR OFF
Volt
65 – 225
225
Pr47
M10 – 04 – 10
Keypad lock enable
KEY LOCK
On – Off
On – Off
Off
Pr48
M10 – 04 – 11
Time after which an alarm is triggered in the event of a blackout
BLACK OUT TIME
Seconds
0 – 60
30
Pr49
M10 – 04 – 12
Time after which the alarm “NO PELLET” goes if“PELLET RESERVE”
RESERVE ALARM
Minutes
1 – 180
60
Pr50
M10 – 04 – 13
Enable pellet level sensor (on prepared models only)
PELLET RESERVE
On – Off
On – Off
Off
Parameters “FACTORY CALIBRATIONS” – Mod. A120 (L09_161018)
Parameter
Menu level
Description
Display
Measurement
Value field
Database
o3
Pr01
M10 – 05 – 01
Ignition cycle maximum time
IGN. TIME
Minutes
5 – 25
18
Pr02
M10 – 05 – 02
Flame stabilisation time following ignition
STAB. TIME
Minutes
0 – 15
9
Pr03
M10 – 05 – 03
Time interval between the two brazier cleaning operations
INT. CLEAN
Minutes
3 – 240
60
Pr04
M10 – 05 – 04
Screw feed gear motor ON time in ignition phase
SC.F. IGNITION
Seconds
0.1 – 8.0
0,8
