If a temperature sensor is connected, this indicates the temperature in ducted room 2 measured by the same.
If a room thermostat is connected, this indicates the status of the same
(OFF = R.T. contact OPEN = Thermostat not in demand)
(
ON = R.T. contact CLOSED = Thermostat in deman
d)
EX.RPM Indicates the speed of the flue extractor fan.
LOAD Indicates the pellet loading interval.
R.T. STATUS
Indicates the status of the main room thermostat.
(OFF = R.T. contact OPEN = Thermostat not in demand)
(
ON = R.T. contact CLOSED = Thermostat in deman
d)
SPE.AIR Indicates the speed of the front air fan.
SPE.DUC1 Indicates the speed of ducted air fan 1.
SPE.DUC2 Indicates the speed of ducted air fan 2.
TIMER 1 Indicates the end (minutes) of the current operating phase.
TIMER 2 Indicates the end (seconds) of the current operating phase.
DEL.ALARM Indicates in an alarm state, the time (seconds) before the alarm condition is shown on the display.
T.CARD. Indicates the temperature read by the sensor inside the control unit.
CLEANER
Indicates the status of the brazier cleaner.
(OFF = Contact OPEN = Brazier not aligned)
(
ON = Contact CLOSED = Brazier
align
ed
)
LEV.PELLET
Indicates the status of the pellet level sensor in the tank.
(OFF = Sensor covered = Pellets in the tank above the reserve limit)
(
ON = Sensor covered = Pellets in the tank below the reserve
limit)
SERVICE Indicates the hours remaining before servicing, to be requested from the Technical Assistance Centre.
MENU 08 – WIFI STATUS (Menu not used)
MENU 09 – USER CALIBRATION *
Menu dedicated to expert users only; allows you to carry out a limited calibration of the pellet load (PELLET TYPE) and flue gas extractor (FLUE
TYPE) as shown in the table below:
Menu Meaning Values that can be set
PELLET TYPE
By increasing the value by a single unit, the pellet load is increased by approximately 4%.
-9 / +9
By decreasing the value by a single unit, the pellet load is decreased by approximately 4%.
FLUE TYPE
By increasing the value by a single unit, the flue gas extraction speed (and thereby the intake of
combustion air
)
is increased
by
a
pp
roximate
ly 3%
.
-9 / +9
By decreasing the value by a single unit, the flue gas extraction speed (and thereby the intake of
combustion air
)
is decreased
by
a
pp
roximate
ly 3%
.
* Access by non-expert users can cause serious damage to the equipment, to things and the environment as well as personal injuries.
Klover declines any responsibility for damages arising from inappropriate calibration.
MENU 10 – TECHNICAL CALIBRATION
Allows you to access all data reserved for the Technical Assistance Centre. Access is protected by a password. Unauthorised access can cause
serious damage to the equipment, to things and the environment as well as personal injuries.
MENU 11 – RELAX FUNCTION (Menu not available)
Allows for reducing the front air fan speed for a pre-set time (90 min).
MENU 12 – SET ROOM. DUC. (Menu displayed only on models with this function)
Allows you to access and modify the room temperature of zone 1 and zone 2 controlled by the associated fans (see also “Modify ducted air speed Set
values”)
