SOFT 80, SOFT 100 PELLET-BURNING STOVE
EN - Rev. 1.0
Technical sheet for SOFT 80 connections
Description of connections
A = Intake pipe
50 mm
Sb = Rear flue gas outlet
80 mm M
Su = Upper flue gas outlet
80 mm M
E = Electricity connection
REAR VIEW
