SOFT 80, SOFT 100 PELLET-BURNING STOVE
EN - Rev. 1.0
Technical specifications SOFT 80
Nominal heat input
kW (Kcal/h)
8,01 (6.889)
Reduced heat input
kW (Kcal/h)
2,70 (2.322)
Nominal heat output
kW (Kcal/h)
7,41 (6.373)
Reduced heat output
kW (Kcal/h)
2,55 (2.193)
Efficiency at nominal heat output
%
92,5
Efficiency at reduced heat output
%
94,5
CO at 13% oxygen at nominal heat output
%
0,012
CO at 13% oxygen at reduced heat output
%
0,054
Maximum power uptake
Watt
340*
Power uptake when running
Watt
30
Nominal voltage
V
230
Nominal frequency
Hz
50
Flue outlet diameter
mm
80
Air intake pipe diameter
mm
40
Minimum chimney draught at nominal heat output
Pa
10,4
Minimum chimney draught at reduced heat output
Pa
9,8
Combustion gas mass at nominal heat output
g/s
5,6
Combustion gas mass at reduced heat output
g/s
3,5
Pellet tank capacity
kg
20
Average exhaust flue gas temperature at nominal heat output
°C
115
Average exhaust flue gas temperature at reduced heat output
°C
60
Width
mm
480
Height
mm
1050
Depth
mm
525
Minimum safety distance from flammable materials (side/rear/front)
mm
200 / 200 / 800
Weight
kg
145
* Power consumption only during the ignition cycle.
The appliance’s heat output may vary in relation to the type of pellets used.
