26
8-ROW 36” STACK-FOLD RIPPER BEDDERS
(
68-08-36-R)
(Shown with Reset-on-the-Go Shanks)
18
TYP.
36
TYP.
69 3/4
TYP.
36
TYP.
45
TYP.
99
TYP.
151 1/4
TYP.
72
168
72
293 5/8
317 3/8
76
TYP.
34 1/4
TYP.
109 3/4
TYP.
142 1/4
TYP.
63 1/2
TYP.
