The KMC 6800 Series Ripper Bedder unit can be equipped with bedders, bedder doors and shaper kits.
The following diagram shows the relationship that each of these set-ups have with the backside of the rear 7x7 tube on any of
the KMC 6800 Series Ripper Bedder toolbars. With each of these distances it can be determined, in conjunction with the KMC Lift
Assist owner’s manual, which set of Lift Assist beams or Planter Beams will be needed to provide clearance between the Ripper Bedder toolbar and the Planter toolbar for the particular KMC Ripper Bedder setup used.
REAR DISTANCES FOR STD. BEDDER CONFIGURATIONS:
REAR DISTANCES OF BEDDER CONFIGURATIONS
WITH BED SHAPER KIT
75
112
