4 I English 3522
1 TECHNICAL DATA
Type
3522
Dimensions mm
345/525
Weight kg (without fasteners)
4.1 kg
Single sequential actuation
Recommended operating pressure
range
5-8.5 bar/
0.5-0.85 MPa
Maximun permissible operating
pressure
8.5 bar/
0.85 MPa
Air consumption per driving
operation
2.8 l at 6
bar / 0.6 MPa
Magazine capacity No. of fasteners
50
Penetration depth setting
no
Fastener: Plastic bound nail
Nail length mm
40-60
Nail shank Ø mm
4.0
Recommended lubricant
1 litre special oil. Code No.
9 4420
250 cm3 grasa especial. Code No.
68 3868
2
NOISE / VIBRATION INFORMATION
Noise characteristic values * 3522
A-weighted single-event emission
sound pressure level at work
station L pA, 1s 94 dB(A)
A-weighted sound power level
L WA, 1s, d
107 dB(A)
Vibration characteristic values **
Weighted r.m.s.-acceleration (a)
3.0 m/s2
The noise level when working can exceed 85
*
**
dB (A). Wear ear protection!Measured
values determined according to EN
12549:1999.
Measured values determined according to
ISO 8662-11:1999.
3
SUPPLIED WITH
1
1
1
4
FILLING THE MAGAZINE
Only those fasteners specified under technical data
(see 1) may be used.
When filling the magazine, hold the tool so that the
muzzle is not pointing towards own body or towards
any other person.
Do not load the tool with fasteners with the safety
yoke or trigger depressed.
Pull pusher back until it has reached the point where
there is noticeable resistance and it catches. Introduce
2 nail strips into the magazine, unlock pusher and lead
it against the nail strip. Make sure that the nail strips
lie correctly in the magazine and that the pusher nose
reaches over the head of the last nail. Never should the
pusher be allowed to snap forward in a magazine
which is half or totally empty. Always guide it by hand
up to the nail strip or stop.
5
HANDLING THE TOOL
Having checked that the fastener driving tool is
functioning correctly, apply the tool to a work piece
and actuate the trigger.
Carefully insert the projecting nail tip into the
appropriate hole in the sheet, press the machine
firmly against the workpiece and pull the trigger
(70008). Release the trigger after the nailing stroke
and remove the tool.
The tip of the nail must be inserted in the intended
hole. Do not nail directly into sheet.
6
ACCESSORIES
Code No.
Suspension
71 3287
Balancer for 30-55 N (3.0-5.5 kp),
cable travel 2.0 m 28 6478
Anchoring nailer
Tool use and safety instructions
Technical data sheet
KMR
